Auto Hexagonal Gabion Mesh Machine To Make Galvanised Gabion Boxes

Auto Hexagonal Gabion Mesh Machine To Make Galvanised Gabion Boxes
Auto Hexagonal Gabion Mesh Machine To Make Galvanised Gabion Boxes

Büyük resim :  Auto Hexagonal Gabion Mesh Machine To Make Galvanised Gabion Boxes

Ürün ayrıntıları:

Place of Origin: Jiangsu, China
Marka adı: Konson
Sertifika: CE, ISO9001, SGS, ASTMA, EN, BS standard.
Model Number: KS80100-3.2

Ödeme & teslimat koşulları:

Minimum Order Quantity: 1 Set
Fiyat: Discuss in mail
Packaging Details: One 40' Open Top Container, wooden pallet, as your design
Delivery Time: within 30 days in receiving prepayment
Payment Terms: L/C, T/T
Supply Ability: 10 Sets per Month
Detaylı ürün tanımı
Vurgulamak:

gabion mesh machine

,

wire mesh machine

Auto Hexagonal Gabion Mesh Machine To Make Galvanised Gabion Boxes

1. Introduction
The KS series gabion mesh machines include four main standard parts: Main netting machine, Winding machine, Wire tension device and Spiral coiling machine, it can produce gabions of various widths and mesh sizes.
KS Gabion Machine
1 automatic, higher efficiency
2 inside winding device
3 overload protect clutch

4 CE certification



2.Specification

KS machine is designed to produce hexagonal mesh of various widths and sizes:

MODEL

MESH SIZE

MAX.WIRE DIA.

MAX WIDTH

PRODUCING RATE

KS6080-2.4

60X80

mm

3.0mm

2400mm

>3.3 m/min

KS6080-3.2

3.5mm

3200mm

KS6080-4.0

3.5mm

4300mm

KS80100-2.4

80X100

mm

3.5mm

2400mm

>3.5 m/min

KS80100-3.2

3.5mm

3200mm

KS80100-4.0

4.0mm

4300mm

KS100120-2.4

100X120

mm

3.5mm

2400mm

>3.5 m/min

KS100120-3.2

3.5mm

3200mm

KS100120-4.0

4.0mm

4300mm

KS120150-2.4

120X150

mm

4.0mm

2400mm

>3.8 m/min

KS120150-3.2

4.0mm

3200mm

KS120150-4.0

4.0mm

4300mm

We can also manufacture special size machine according to customer request.

 Auto Hexagonal Gabion Mesh Machine To Make Galvanised Gabion Boxes 0
KS series wire mesh machine is only for export, we exported our equipments to Russia, Turkey, Poland, Croatia, Bulgaria, Algeria, Morocco, Ethiopia and etc. Your any enquiry will be replied within 12 hours.



Auto Hexagonal Gabion Mesh Machine To Make Galvanised Gabion Boxes 1
